供应优质东莞飞龙达45电线高速押出机（挤出机）

机器型号
Type

fld30

fld40

fld50

fld60

机器用途
Pourpose

适用于导体单层押出,Foam-Skin化学发泡双层押出,单层+注条押出
Used in conductor single layer extrusion,Foam-Skin chemical double layer extrusion,single layer+pours the strip extrusion

芯线规格
Core Specification

AWG36~AWG30

AWG32~AWG28

AWG30~AWG26

AWG28~AWG20

押出材料
Extrusion material

HDPE、Foam-PE、PP、PU 、PVC、SR-PVC

螺杆参数
Screw parameter

长径比:26~28    压缩比:2.7~3.2    螺杆材料:SACM眞空热处理,表面研磨镀铬抛光
L/D ratio   Compression ratio :2.7-3/2  screw materail:SACM  vacuum heat treatment

温控段数(机筒+机头)
Tempretuer group (Body+Head)

3+3

3+3

4+3

4+3

加热功率

6KW

8KW

11KW

15KW

主机动力
Power of main machine

7.5HP

10HP

15HP

20HP

最高产量
The highest output

30KG/H

45KG/H

60KG/H

85KG/H

最高线速
limted wire speed

300M/MIN

400M/MIN

600M/MIN

800M/MIN

活动水槽
cooling station

伸缩式活动水槽 / 恒温活动水槽,加热功率9KW,移动量500,总长度1.7M,配双段式拭水器
Extension type cooling station/ constant temperature cooling station ,heating power 9KW,emigration quantity 500,length1.7M ,with duble water

U型水槽长度
Utype cooling length

6M

8M

8M

10M

蓄线参数
Accumulate parameter

Φ120~180蓄线轮,固定轮10沟+移动轮11沟,水平 / 斜式蓄线架,长度9M,蓄线量200M
Φ120-180 accumulate wheel,fix wheel 10pcs+moving wheel,standard/inclined accumulate shift ,length 9M,accumulate quantity200M

引取功率
Drum power

3HP

3HP

3HP

5HP

放线型式
Pay-off type

琴式张力被动放线 / 无轴式动力放线,摆杆滑块式张力器,设断线保护,适用于Φ300~500线轴Pay-off/none shift power take-up,oder protection,used in 300-500shift.

收线型式
Take-up type

双轴收线,光杆扁平电缆,2HP马达配变频调速,可单动/联动运转,米到停机,适用于Φ400~500线轴Double shift take-off,2HPmotor with Frequency conversion adjust speed,could be single/linkage running,machine stop with the oder meter over,suitablein 400-500shift.
