- 耐高温，高阻燃
- 耐磨损
- 在高温下耐腐蚀
- 径向收缩比：2:1，轴向收缩率≤10%
- 收缩温度：开始收缩温度110 ℃，完全收缩温度200 ℃
- 工作温度：-55 ℃~200 ℃
- 管体柔韧
|
应用
高温有油环境电子元件的保护；电阻电容器、热电偶的绝缘及保护；各种金属线类的机械保护；电线末端、接续、端子的绝缘、保护和补强。中科英华(原长春热缩)系直九标准推荐生产厂家
| 技术指标 |
| 项目 |
|
性能 |
|
指标
|
|
典型值
|
|
测试标准
|
| |
|
|
|
|
|
|
|
|
| |
| |
| 机械性能 |
|
拉伸强度 |
|
>12MPa
|
|
>12MPa
|
|
ASTM D2671
|
| |
|
|
|
|
|
|
|
| |
断裂伸长率 |
|
≥250%
|
|
430%
|
|
ASTM D2671
|
| |
|
|
|
|
|
|
|
| |
老化后断裂伸长率(250 ℃ /168hrs) |
|
≥200%
|
|
250%
|
|
ASTM D2671
|
| |
|
|
|
|
|
|
|
| |
热冲击 (300 ℃ /4hrs) |
|
pass
|
|
no dripping
|
|
ASTM D2671
|
| |
|
| |
低温柔韧性 (-55 ℃ /4hr) |
|
pass
|
|
Pass
|
|
ASTM D2671
|
| |
| 电性能 |
|
介电强度 |
|
>25kV/mm
|
|
>25kV/mm
|
|
ASTM D2671
|
| |
|
| |
体积电阻率 |
|
>1014Ω.cm
|
|
>1016Ω.cm
|
|
ASTM D 257
|
| |
| 化学性能 |
|
铜腐蚀 (250 ℃ /168hrs) |
|
No Corrosion
|
|
Pass
|
|
ASTM D2671
|
| |
|
| |
铜稳定 (121 ℃ /168hrs) |
|
Elongation>70%
|
|
pass
|
|
UL 224
|
| |
|
| |
阻燃性能 |
|
|
|
Highly Flame Retardant
|
|
ASTM D2671
|
| |
|
|
|
|
|
|
|
| |
吸水率 |
|
<0.5%
|
|
<0.5%
|
|
ASTM D570
|
| |
|
| |
抗真菌性 |
|
|
|
Very Good
|
|
ISO 846
|
|
| 规格尺寸 |
| |
|
规格
|
内径
|
完全收缩后平均壁厚
|
| |
|
收缩前最小内径
|
收缩后最大内径
|
| |
|
mm
|
inch
|
mm
|
inch
|
mm
|
inch
|
mm
|
inch
|
| |
|
|
|
|
|
|
|
|
1.2
|
3/64
|
1.20
|
0.047
|
0.60
|
0.024
|
0.25±0.1
|
0.010±0.004
|
| |
|
1.6
|
1/16
|
1.60
|
0.063
|
0.80
|
0.032
|
0.25±0.1
|
0.010±0.004
|
| |
|
2.4
|
3/32
|
2.40
|
0.094
|
1.20
|
0.047
|
0.25±0.1
|
0.010±0.004
|
| |
|
3.2
|
1/8
|
3.20
|
0.126
|
1.60
|
0.063
|
0.25±0.1
|
0.010±0.004
|
| |
|
4.8
|
3/16
|
4.80
|
0.189
|
2.40
|
0.095
|
0.30±0.1
|
0.012±0.004
|
| |
|
6.4
|
1/4
|
6.40
|
0.252
|
3.20
|
0.126
|
0.30±0.1
|
0.012±0.004
|
| |
|
9.6
|
3/8
|
9.60
|
0.378
|
4.80
|
0.189
|
0.30±0.1
|
0.012±0.004
|
| |
|
12.8
|
1/2
|
12.80
|
0.504
|
6.40
|
0.252
|
0.30±0.1
|
0.012±0.004
|
| |
|
19
|
3/4
|
19.00
|
0.748
|
9.50
|
0.374
|
0.40±0.1
|
0.016±0.004
|
| |
|
25.4
|
1
|
25.40
|
1.000
|
12.70
|
0.500
|
0.50±0.1
|
0.020±0.004
|
| |
|
38
|
1 1/2
|
38.00
|
1.496
|
19.00
|
0.748
|
0.50±0.1
|
0.020±0.004
|
|
点击图片查看原图
