| LCP 6130 美国杜邦公司 物性数据 |
| 暂无此原料描述部分┄ |
| 性能项目 | 试验条件[状态] | 测试方法 | 测试数据 | 数据单位 | ||||||||
| 基本性能 | 吸水率 | --- | --- | 0.002 | % | |||||||
| CTI UL标准值 | --- | --- | 4 | --- | ||||||||
| 物理性能 | 纤维含量 | --- | --- | 30 | % | |||||||
| 比重 | --- | --- | 1.62 | --- | ||||||||
| 机械性能 | 引张强度 | --- | --- | 150 | MPa | |||||||
| 拉伸强度 | --- | --- | 2.7 | % | ||||||||
| 弯曲强度 | --- | --- | 170 | MPa | ||||||||
| 弯曲弹性率 | --- | --- | 12 | GPa | ||||||||
| 冲击强度 | --- | --- | 120 | j/m | ||||||||
| 洛氏硬度 | --- | --- | 108 | R | ||||||||
| 电气性能 | 诱电率 | --- | --- | 3.9 | --- | |||||||
| 绝缘破坏电压 | --- | --- | 26 | MV/m | ||||||||
| 加工性能 |
|
--- | --- |
|
|
|||||||
| 热 性 能 | 线膨胀系数 | --- | --- | 1.3(3.7) | 10-5k | |||||||
| 热变形温度 | 0.46Mpa | --- | 277 | ºC | ||||||||
| 热变形温度 | 1.82Mpa | --- | 265 | ºC | ||||||||
| 燃烧性 | --- | --- | V-0（0.2) | --- | ||||||||
