产品名称:RVVP型铜芯聚氯乙烯绝缘屏蔽聚氯乙烯护套软电缆
产品概述:
应用范围:
本产品适用于智能建筑楼宇自动化控制系统,防盗报警,一卡通系统,智能家居,机械仪表和电子设备等需要抗干扰防屏蔽系统用线
产品信息:
产品型号:RVVP
参考标准:JB/T8734.5—2012
额定电压:U0/U为300/300V
额定温度:70度
基本结构:导体为高纯无氧铜导体及镀锡铜导体,绝缘为PVC/D, 护套为PVC/ST5
屏蔽采用裸铜丝高密度编织或缠绕,有效阻隔外界电磁干扰
使用特性
电缆长期允许工作温度应不超过70度
电缆敷设温度应不低于0度
100m/200m/300m每卷或定制长度
屏蔽采用裸铜丝高密度编织或缠绕,有效阻隔外界电磁干扰
护套采用优质聚氯乙烯材质,抗老化,耐磨损,防水,防油,防化学腐蚀,无毒等特性
允许弯曲半径,电缆外径D小于25mm时,应不小于4D,电缆外径D为25mm及以上应不小于6D
RVVP系列
|
||||||||
产品编号
|
芯数×标准
截面mm2 |
绝缘厚度
规定值mm |
屏蔽密度≥%
|
护套标称
厚度mm |
平均外径mm
|
20℃时导体电阻最大值Ω/km
|
70℃时绝缘电阻
最小值MΩ/km |
|
下限
|
上限
|
|||||||
AP-10-001
|
1×0.12
|
0.4
|
60
|
0.4
|
2.4
|
2.9
|
158
|
0.018
|
AP-10-002
|
2×0.12
|
0.4
|
80
|
0.6
|
3.7
|
4.9
|
158
|
0.016
|
AP-10-003
|
3×0.12
|
0.4
|
80
|
0.6
|
3.9
|
5.1
|
158
|
0.016
|
AP-10-004
|
4×0.12
|
0.4
|
80
|
0.6
|
4.5
|
5.8
|
158
|
0.016
|
AP-10-005
|
5×0.12
|
0.4
|
80
|
0.6
|
4.8
|
6.2
|
158
|
0.016
|
AP-10-006
|
6×0.12
|
0.4
|
80
|
0.6
|
5.2
|
6.6
|
158
|
0.016
|
AP-10-007
|
7×0.12
|
0.4
|
80
|
0.6
|
5.2
|
6.6
|
158
|
0.016
|
AP-10-008
|
8×0.12
|
0.4
|
80
|
0.6
|
5.4
|
6.8
|
158
|
0.016
|
AP-10-009
|
9×0.12
|
0.4
|
80
|
0.6
|
5.8
|
7.2
|
158
|
0.016
|
AP-10-010
|
10×0.12
|
0.4
|
80
|
0.6
|
6.4
|
8.1
|
158
|
0.016
|
AP-10-011
|
12×0.12
|
0.4
|
80
|
0.6
|
6.6
|
8.3
|
158
|
0.016
|
AP-10-012
|
14×0.12
|
0.4
|
80
|
0.8
|
7.2
|
9.1
|
158
|
0.016
|
AP-10-013
|
15×0.12
|
0.4
|
80
|
0.8
|
7.6
|
9.5
|
158
|
0.016
|
AP-10-014
|
16×0.12
|
0.4
|
80
|
0.8
|
7.6
|
9.5
|
158
|
0.016
|
AP-10-015
|
18×0.12
|
0.4
|
80
|
0.8
|
8.2
|
10.3
|
158
|
0.016
|
AP-10-016
|
19×0.12
|
0.4
|
80
|
0.8
|
8.2
|
10.3
|
158
|
0.016
|
AP-10-017
|
20×0.12
|
0.4
|
80
|
0.8
|
8.3
|
10.5
|
158
|
0.016
|
AP-10-018
|
24×0.12
|
0.4
|
80
|
0.8
|
9.4
|
11.7
|
158
|
0.016
|
AP-10-019
|
1×0.2
|
0.4
|
60
|
0.4
|
2.6
|
3.2
|
92.3
|
0.013
|
AP-10-020
|
2×0.2
|
0.4
|
60
|
0.4
|
4.1
|
5.3
|
92.3
|
0.013
|
AP-10-021
|
3×0.2
|
0.4
|
80
|
0.6
|
4.5
|
5.8
|
92.3
|
0.013
|
AP-10-022
|
4×0.2
|
0.4
|
80
|
0.6
|
4.9
|
6.2
|
92.3
|
0.013
|
AP-10-023
|
5×0.2
|
0.4
|
80
|
0.6
|
5.3
|
6.7
|
92.3
|
0.013
|
AP-10-024
|
6×0.2
|
0.4
|
80
|
0.6
|
5.7
|
7.2
|
92.3
|
0.013
|
AP-10-025
|
7×0.2
|
0.4
|
80
|
0.6
|
5.7
|
7.2
|
92.3
|
0.013
|
AP-10-026
|
8×0.2
|
0.4
|
80
|
0.6
|
6.0
|
7.5
|
92.3
|
0.013
|
AP-10-027
|
9×0.2
|
0.4
|
80
|
0.6
|
6.6
|
8.0
|
92.3
|
0.013
|
AP-10-028
|
10×0.2
|
0.4
|
80
|
0.8
|
7.4
|
9.3
|
92.3
|
0.013
|
AP-10-029
|
12×0.2
|
0.4
|
80
|
0.8
|
7.6
|
9.6
|
92.3
|
0.013
|
AP-10-030
|
14×0.2
|
0.4
|
80
|
0.8
|
8.2
|
10.3
|
92.3
|
0.013
|
AP-10-031
|
15×0.2
|
0.4
|
80
|
0.8
|
8.8
|
10.8
|
92.3
|
0.013
|
AP-10-032
|
16×0.2
|
0.4
|
80
|
0.8
|
8.8
|
10.8
|
92.3
|
0.013
|
AP-10-033
|
18×0.2
|
0.4
|
80
|
0.8
|
9.0
|
11.8
|
92.3
|
0.013
|
AP-10-034
|
19×0.2
|
0.4
|
80
|
0.8
|
9.0
|
11.8
|
92.3
|
0.013
|
AP-10-035
|
20×0.2
|
0.4
|
80
|
0.8
|
9.3
|
12.1
|
92.3
|
0.013
|
AP-10-036
|
24×0.2
|
0.4
|
80
|
0.8
|
10.4
|
12.9
|
92.3
|
0.013
|
以上参数是一部分而已且供参考,具体标准与我们工作人员联系
